  • Newmar 12-12-35I DC Converter [12-12-35I]

    • Newmar 12-12-35I DC Converter [12-12-35I]

    Newmar Power

    $2,228.34
    (No reviews yet) Write a Review
    SKU:
    BSM-102293
    MPN:
    12-12-35I

    Product Description

    12-12-35I DC Converter

    This isolated series provides voltage conversion as well as input/output isolation, allowing the use of negative ground gear in positive or floating ground battery systems, or vice versa.

    Using an isolated converter as a voltage stabilizer on 12- or 24-volt systems can solve conducted noise and interference problems on sensitive DC-powered communication, navigation systems, and DC microprocessor-based devices.

    Features:

    • Wide range of input voltage
    • Precise output voltage regulation
    • Reverse polarity
    • Input fuse/output fuse
    • Total input/output isolation, pos. or neg. ground
    • Current-limiting, short-circuit-proof output
    • Automatic resetting of the thermal shutdown
    • High/low input voltage shutdown
    • Polyurethane conformal coating on PC board
    • Power ON light
    • Rugged case designed for high-vibration applications

    Specifications:

    • Input Voltage: 10-16
    • Max Input Amps: 56
    • Output Voltage: 13.6
    • Output Amps (Intermittent): 35
    • Output Amps (Continuous): 20
    • Case Size (H x W x D): 6 x 6.8 x 16.5 inches (15.2 x 17.3 x 41.9 centimeters)
    • Weight: 12 lb. (5.5 kg)
    • Output: 13.6 VDC (internally adjustable 12.6 -14.5) or 24.5 VDC (or specify)
    • Ripple: 150 mV P-P maximum
    • Regulation: 1% Line/Load
    • Duty Cycle Ratings: Intermittent – 20 minutes max on time, 20% duty. current limit set at approx. 105% of the intermittent rating. Continuous – 24 hours, 100% duty
    • Idle Current: Less than 100 mA (including power “ON” light )
    • Operating Temp: 0-50 degrees C, Derate Linearly From 100% @ 40 degrees C To 50% @ 50 degrees C. Thermal shutdown @ 70 degrees C Case Temperature
    • Switching Frequency: 40 kHz
    • Efficiency: 85% – Typical
    • Isolation – Output/Chassis; Input/chassis: 250 VDC

    Mechanical Specifications:

    • Anodized aluminum heat sink case
    • Front panel terminal block
    • Heavy-duty mounting flange
    • conformal-coated PC board

    Options:

    • Operation as battery charger or parallel redundant operation* – derate to continuous duty rating (contact factory)
    • Extreme vibration mounting kit. (Information below)

    Option: Extreme Vibration Mounting Kit

    The Extreme Vibration Mounting Kit is available to protect NEWMAR power converters from the extreme stresses of shock and vibration when mounted on high-vibration vehicles.

    The kit replaces the standard vibration kit provided with the unit and fits into the unit’s mounting flange to act as a ‘super shock absorber’ for electronics in high-vibration applications. It is available to fit all NEWMAR units from 2 to 70 lbs. Specify Kit L for units that weigh 2 -15 lbs. and Kit H for units that weigh 16 – 70 lbs.

    This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.
